1. Comler Power (1500/1800r/min) series brushless three-phase AC synchronous generator adopts a unique forming hard coil winding process and uses VPI vacuum pressure impregnation technology to insulate the winding stator and rotor, greatly improving the insulation strength between turns and phases of the generator, ensuring the operational reliability of the generator and further improving its service life.
2. The overall convex rotor has a sturdy winding and a unique iron core ventilation structure. After special treatment, the winding has good heat dissipation effect and is equipped with a fully damped winding for stable parallel operation;
3. Steel plate machine base, overall sturdy and reliable, with a novel design;
4. Automatic voltage regulation: high precision, with the characteristics of low-speed protection and reliable adjustment during parallel operation. The overall sealing process and three anti vibration properties are good;
5. According to different installation requirements, there are two types of structures: single bearing and double bearing. The single bearing structure adopts the internationally recognized SAE standard flywheel interface and coupling plate connection, and can also be customized with non-standard connections; The transmission end cover of the double bearing structure has three forms: flange cover, integrated cover, and ordinary cover.
6. A high-performance AVR voltage regulator, even under distorted load conditions, has the characteristics of low-speed protection and reliable differential adjustment during parallel operation. It has good overall sealing technology, three protections, and anti vibration performance;
(1) Adaptability to various harsh environments such as landfills, sewage treatment plants, coalbed methane, and oil fields.
(2)The optimized winding design ensures better performance in both 50Hz and 60Hz scenarios, with multiple winding forms to meet the voltage requirements of different usage scenarios. The standard design of generator stator winding has good performance under distorted load conditions.
(3)The higher power generation efficiency ensures that the unit can provide more electricity.
(4)Wide range of use: telecommunications and Internet services; Parallel operation of generator sets; In the field of renewable energy, landfills, sewage treatment plants, etc; Coalbed methane, oil fields, and natural gas fields.
(5)A reliable AVR regulator can ensure a qualified voltage regulation rate even under distorted load conditions, and also improve the anti-interference ability of the generator.
Radiator
Equipped with a 52 degree radiator, cooled by water cooling. Efficent operate under full load and high temperature conditions, Right for operation in low latitude tropical regions.
Controller: Comler fifth generation interconnected microcomputer intelligent control system, British deep-sea DSE7320
1. Microcomputer operation template, LCD display, with backlight, realizing the self starting and self stopping functions of the generator set.
2. With four protection functions, the mains power has overvoltage, undervoltage, and missing item detection functions, and the power generation has overvoltage, undervoltage, overclocking, and overcurrent detection functions.
3. Supports multiple types of engines, displays various parameters of the engine, generator, and generator set, and provides shutdown protection when the values are unstable.
4. Upgrade software version, customers can upgrade firmware version as needed to meet technical requirements.
5. Language: 13 languages for Choice
6. Four sets of working modes and protection parameters can be set.
7. Can preset operating time (the unit can be started regularly for maintenance) and maintenance cycle function (the engine needs to replace the three filters after 250 hours of operation)
8. Remote monitoring of the system can be achieved: RS485 transmission can reach up to 1200 meters. DSE7320+DSE890 can achieve network monitoring
9. Reserved automation interface, a system within the microcomputer control system that can achieve automation functions.
Base of Generator set:
The base is produced using a sheet metal assembly line, calibrated by a balance meter, and the entire unit is placed on a steel frame base. It is equipped with a dedicated shock absorber for the unit, ensuring smooth and reliable operation and easier maintenance.
