1. Clean and environmentally friendly: Compared to diesel, Natural gas genertor sets could control emissions, with NOx reduced by up to 40% and PM reduced to 0;
2. Low cost and wide application: Natrual gas consumption rate below 185g/kw. h
3. Speed regulation performance: advanced electronic control technology, combined with variable electronic throttle technology, and speed closed-loop contro. Steady state speed fluctuation rate ≤ 1%, fast transient response speed.
4. Startup performance: The unit is equipped with an international brand ignition system, which has undergone strict testing and has a high success rate for startup. It only takes 30 seconds from successful cold start to full load operation.
5. Mature technology
(1) Low voltage system
(2) Medium and High Voltage System
① International advanced single point injection technology
② Turbocharged intercooled lean combustion technology
③ Electronic boosting technology
④ Oxygen sensor closed-loop control technology
⑤ Single cylinder independent ignition technology
⑥ Fault diagnosis technology
6. Island operation: A local power grid constructed by multiple units working together can provide power guarantee for surrounding electrical equipment;
7. Parallel grid connection:
With Deep-sea controller 8610 it can control 32 generator sets at same time. Complete functionality, high degree of automation, reliable operation, easy maintenance, and economical operation.
(1)Parallel operation: After multiple units are combined, an appropriate number of units can be deployed according to the load size to ensure that the units operate in good condition. This can reduce fuel and oil losses, minimize unit failures, and bring significant economic benefits to the enterprise;
(2) Stable: After being connected, the power supply quality is improved, the voltage and frequency of the electrical equipment are stable, and it can withstand the impact of large loads on the generator. Installing a PMG system on each gas turbine can effectively enhance the anti-interference ability of the unit;
(3)Control: After the units are connected in parallel, they become an integrated power grid, and with centralized control, power dispatching is convenient.
8. Low Noise, dust prevention, and rain prevention: Installing a generator set soundproof box and using specialized noise reduction and soundproofing materials can greatly reduce the mechanical noise extension, reducing the noise to below 75 decibels. It has multiple functions such as rain prevention, dust prevention, and insulation.
9. Convenient operation: Equipped with ATS and high-performance intelligent electrical system, the unit can automatically start and stop, switch freely between mains power and electromechanical power, and monitor the operation status of the unit without human supervision.
10. Remote management: wireless transmission to access the Internet can remotely manage the standby and operation of the generator set around the clock, automatically process all data of the unit, and make the unit operate more efficiently.
